SX1200.1 (24V)

Mono Class D Digital Amplifier

With the SIGNUM SXT power amplifiers, ESX opens a new chapter in mobile amplifier technology. Designed specifically for trucks with 24V electrical systems, these German-engineered amplifiers offer outstanding sound, massive power, and maximum reliability – exactly what you need for everyday use on the road. The one-piece die-cast aluminum heat sinks ensure optimal heat dissipation and provide a sophisticated look. Combined with modern Class D technology, the ESX amps are compact, highly efficient, and incredibly powerful. Perfect for anyone who demands top-notch sound, even in a truck.



The SXT1200.1 is the top choice for uncompromising 24V bass performance in trucks. All relevant filters and crossovers are integrated, and a bass level remote is included as standard. This compact monoblock delivers a solid 900 watts RMS at 2 ohms and an even more powerful 1,200 watts RMS at 1 ohm – remarkable considering its compact design. In the Car&Hifi test (issue 1/2026), the ESX amplifier performed even better: a remarkable 1,374 watts RMS were measured at 1 ohm. This further demonstrates how conservatively ESX calculates its power ratings. For this outstanding performance, the amplifier not only received the POWER TIP but also the highest possible rating of 1+.

Features

  • Efficient Class D Technology with compact Dimensions
  • Die-cast Aluminum Heatsink with optimal Cooling Properties
  • RCA Inputs, RCA Outputs
  • Compact Bass Remote Controller



  • High Level Inputs with Error Protection System (EPS®)
  • Auto Turn-On Function
  • Start/Stop Ready
  • 1-Ohm stable

Specifications

Mono Class D Digital Amplifier

1 x 600/900/1200 Watts RMS @ 4/2/1 Ω
Subsonic-Filter 10 - 50 Hz

LPF 40 - 250 Hz

Bass Boost 0 - 12 dB

Dimensions 140 x 44 x 225 mm

Efficiency up to 90%

€ 299,00

Manufacturer's suggested retail price, changes and mistakes reserved.
