SX-ONE

Mono Mini Class D Digital Amplifier

With the SIGNUM SX Mini series, ESX expands its extensive car audio portfolio with four brand-new MINI Class-D amplifiers that set new standards with their minimal dimensions, outstanding sound, and surprisingly high power output of up to 600 watts RMS. These compact powerhouses utilize state-of-the-art Class D technology, which, thanks to its high efficiency, enables low heat generation, thus making the exceptionally space-saving design—only 83 mm wide and 38 mm high—possible. This makes the mini amplifiers ideal for discreet installations, whether under the seat, in the side panel, or in the trunk. A particularly practical feature: The SX-FIVE, SX-TWO, and SX-ONE models come with a bass level remote control. This allows for convenient bass adjustment from the driver's seat at any time—perfect for those who value flexibility and maximum control in everyday driving.



The SX-ONE is the top choice in our portfolio when it comes to driving subwoofers. This mini monoblock delivers enormous power, up to 600 watts RMS at 1 ohm, while remaining remarkably compact. State-of-the-art Class-D technology ensures efficient operation, stable power, and controlled deep bass.

Features

  • Efficient Class D Technology with compact Dimensions
  • Die-cast Aluminum Heatsink with optimal Cooling Properties
  • RCA Inputs via Cable Connector
  • Compact Bass Remote Controller



  • High Level Inputs with Error Protection System (EPS®)
  • Auto Turn-On Function
  • Start/Stop Ready

Specifications

Mono Mini Class D Digital Amplifier

1 x 200/375/600 Watts RMS @ 4/2/1 Ω

LPF 50 - 250 Hz

Bass Boost 0 - 12 dB

Dimensions 140 x 44 x 225 mm

Efficiency up to 87%

Downloads

Owner's Manual

€ 199,00

Manufacturer's suggested retail price, changes and mistakes reserved.
