QXP104

25 cm (10”) Flat Subwoofer with Protection Grille

With the new QUANTUM QXP subwoofers, ESX is writing the next chapter in powerful bass performance. Following the success of the 8- and 10-inch VISION VXP Flat subwoofers, which have already established themselves as a technological benchmark for uncompromising sound, ESX is now taking performance to a new level – with the QXP Flat subwoofers, which combine power, precision, and efficiency in a completely new class.



The QXP woofers deliver a bass force previously only associated with large, deep-mounted subwoofers. Powerful, dynamic, and with impressive depth, they create goosebumps in your vehicle – making a clear statement in the market. And best of all: despite their enormous performance, the two QUANTUM models, in 10- and 12-inch formats, are extremely compact, with mounting depths of only 82 and 89 mm, respectively.



With a mounting depth of just 82 mm, the QXP104 is among the flattest subwoofers in its class. The real sensation, however, lies in its dynamics: While conventional flat woofers often reach their limits early on, the QXP104 unleashes a sound pressure level usually only expected from significantly larger subwoofers. A sensational Xmax of ±20 mm sets new standards in this segment. The QXP104 delivers this power even in compact, sealed enclosures with a volume of approximately 14 liters. ESX also makes no compromises in its construction: Instead of a simple sheet metal basket, a solid cast aluminum basket is used. An elegant protective grille, included in the package, ensures optimal protection.

Features

  • Robust, flat-design cast aluminum basket
  • Ideal for sealed enclosures from approx. 14 liters
  • 39 mm dual voice coil with 36 mm winding height
  • Y40 dual magnet with 2.3 kg



  • ABS gasket and polypropylene cone
  • Includes metal protection grille
  • X-Max. +/- 20 mm

Specifications

25 cm (10”) Flat Subwoofer

Power Rating 500/1000 Watts Music/Peak

Impedance 4 Ω

Fs 33 Hz, Qts 0,63, VAS 19,5 L, 86 dB/2,83V/1m

Installation depth 82 mm

Installation diameter 236 mm

€ 249,00

Manufacturer's suggested retail price, changes and mistakes reserved.
