QX10BXA

20 cm (8") Downfire Active Subwoofer System

With their extremely compact dimensions, ESX presents two new active down-firing subwoofers that prove to be true space savers. But their compact design is deceptive: thanks to high-quality components such as the new QXP high-end subwoofers and powerful 460-watt Class D bass modules, they deliver top-tier performance and effortlessly handle even the deepest bass attacks.



Their substantial weight alone demonstrates that no compromises have been made. The flat yet solid MDF enclosures with additional internal bracing are extremely robust and effectively suppress unwanted resonances. A particularly practical feature: thanks to the removable feet, the speakers can be perfectly integrated into false floors in car trunks.



The ESX speakers utilize the new, revolutionary QXP flat subwoofers – slim, high-performance drivers that are in a class of their own. With an impressive Xmax of ±20 mm, they deliver a dynamic range and bass power that is hardly conceivable in this form factor. Massive die-cast aluminum baskets and powerful dual magnets ensure maximum stability and perfect control of the diaphragm. The result: a clean, precise, and deep bass performance.



Housed in the high-end QXP enclosures is the multi-award-winning POWER4 Class D active module, which provides ample power reserves with a hefty 1000 watts peak at 4 ohms. The module features sophisticated circuitry at the input: Thanks to the "EPS PRO" high-level input developed by ESX, the module is fully compatible with modern vehicles and their sensitive diagnostic systems. The module is equally uncompromising in its features: adjustable subsonic and low-pass filters, bass boost, and a phase switch allow for precise tuning of the bass response. Signal input is available via RCA or high-level inputs. For maximum comfort, the included bass level remote control allows the bass level to be conveniently adjusted from the driver's seat at any time.

Specifications

25 cm (10") Active Subwoofer System (sealed)

Integrated Class D Amplifier (Power4 Active Module)

1 x 500/1000 Watts Music/Peak

LPF 40-120 Hz @ 12 dB

Phase Shift 0°/180°

Bass Boost 0-6dB @ 45Hz

RCA Low Level Input

High Level Input

Auto Turn-On Function (DC or signal)

Start-stop capable, 5 sec./ up to 7 Volts

EPS® PRO with 10R / 150R / 600R (switchable)

Input Sensitivity 15 or 40 Volts (switchable)

Triple Limiter Function, Clipping LED

Bass Remote Controller

Compact Enclosure with Logo Embroidery

Protection Grille for Subwoofer

Dimensions without feet: 53 x 12.5 x 36 cm

Dimensions with feet: 53 x 15.5 x 36 cm

Downloads

Owner's Manual

€ 449,00

Manufacturer's suggested retail price, changes and mistakes reserved.
